Analyzing Class Initialization for ReadyNow Profiles

Profile Event Format

In a ProfileLogOut dump, class initialization is recorded as event pairs:


<timestamp> | ClassInit <class_id> <had_initializer> <has_default_methods> <tid>
<timestamp> | ClassInitEnd <class_id> <tid>

Timestamps are in nanoseconds, relative from VM start:


delta_ms = (event_timestamp - VmStart_timestamp) / 1_000_000

FintechApp Demo

"FintechApp" is a simple demo application which we built for this guide.

You can view the source code for FintechApp in Example 3: FinTechApp.java

The demo application has two eager classes, MarketDataFeed and OrderRouter, which are initialized at startup. The demo app has two lazy classes, AuditLogger and EndOfDaySettlement, initialized after load start. The app sleeps until load start, triggers lazy class initialization and then stays alive for a time so that the shutdown ClassInit events fall outside the detection window.

Let’s break down what our scripts are doing:

Scripting the Detect, Fix, Verify Flow

To achieve autonomous analysis of class initialization, we need scripts which can detect problems, fix them, and finally verify that the problems no longer persist.

Running the example script, run_demo.sh (see Example 1: run_demo.sh), does the following:


export JAVA_HOME=/path/to/zing25.08.x.x
./run_demo.sh

Step-by-step


JAVA_HOME=/path/to/zing25.08.x.x

$JAVA_HOME/bin/javac src/<FintechApp.java>

$JAVA_HOME/bin/java \
  -XX:ProfileLogOut=fintech_demo \
  -cp src \
  FintechApp 5 10


./detect_post_deadline_classinit.sh fintech_demo 10 10


RESULT: ANALYSIS NEEDED

Post-load-start classes:
  - FintechApp$AuditLogger (+5023ms)
  - FintechApp$EndOfDaySettlement (+5024ms)
  ... (plus JVM-internal classes triggered by them)


FintechApp$AuditLogger
FintechApp$EndOfDaySettlement


$JAVA_HOME/bin/java \
  -XX:+UnlockExperimentalVMOptions \
  -XX:ProfileLogIn=fintech_demo \
  -XX:ProfileLogOut=fintech_demo_fixed \
  -XX:ProfileForceClassInitializationDelaySec=2 \
  -XX:ProfileForceClassInitializationListPath=force_init_classes.txt \
  -cp src \
  FintechApp 5 10


./detect_post_deadline_classinit.sh fintech_demo_fixed 10 10

Example 1: run_demo.sh


#!/bin/bash
#
# run_demo.sh — End-to-end ClassInit closure analysis demo
#
# Builds the app, generates a profile, detects post-load-start ClassInit events,
# creates a force-init list, re-runs with force init, and verifies the fix.
#
# Requires JAVA_HOME to point to a Zing JDK.
#
# Usage:
#   ./run_demo.sh
#
set -euo pipefail

if [ -z "${JAVA_HOME:-}" ]; then
    echo "ERROR: JAVA_HOME is not set. Point it to a Zing 25.08 or later."
    echo "Example: export JAVA_HOME=/path/to/zing25.08.x-jdk21"
    exit 2
fi

JAVAC="$JAVA_HOME/bin/javac"
JAVA="$JAVA_HOME/bin/java"

if [ ! -x "$JAVA" ]; then
    echo "ERROR: $JAVA not found or not executable."
    exit 2
fi

LOAD_START=10
WINDOW=10
FORCE_INIT_DELAY=2
SCRIPT_DIR="$(cd "$(dirname "$0")" && pwd)"
PROFILE_BEFORE="$SCRIPT_DIR/demo_before"
PROFILE_AFTER="$SCRIPT_DIR/demo_after"
FORCE_INIT_LIST="$SCRIPT_DIR/force_init_classes.txt"

echo "============================================"
echo " ClassInit Analysis — End-to-End Demo"
echo "============================================"
echo "JAVA_HOME:  $JAVA_HOME"
echo "Load start: ${LOAD_START}s"
echo "Window:     ${WINDOW}s after load start (ignore shutdown ClassInit)"
echo "Force-init delay: ${FORCE_INIT_DELAY}s (JVM flag, must be < load start)"
echo ""

# ── Step 1: Build ─────────────────────────────────────────────────
echo ">>> Step 1: Compiling FintechApp..."
"$JAVAC" "$SCRIPT_DIR/src/FintechApp.java"
echo "    Done."
echo ""

# ── Step 2: Generate profile (ProfileLogOut) ──────────────────────
echo ">>> Step 2: Running app to generate profile..."
"$JAVA" \
    -XX:ProfileLogOut=demo_before \
    -cp "$SCRIPT_DIR/src" \
    FintechApp "$LOAD_START" "$WINDOW"
echo ""

# ── Step 3: Detect post-load-start ClassInit events ──────────────
echo ">>> Step 3: Detecting post-load-start ClassInit events..."
echo ""
if "$SCRIPT_DIR/detect_post_deadline_classinit.sh" "$PROFILE_BEFORE" "$LOAD_START" "$WINDOW"; then
    echo ""
    echo "No post-load-start ClassInit events. Nothing to fix."
    exit 0
fi
echo ""

# ── Step 4: Extract application classes into force-init list ──────
echo ">>> Step 4: Building force-init class list..."

VMSTART=$(grep '| VmStart' "$PROFILE_BEFORE" | head -1 | awk -F'|' '{print $1}' | tr -d ' ')
LOAD_START_NS=$((LOAD_START * 1000000000))
LOAD_START_TS=$((VMSTART + LOAD_START_NS))
WINDOW_END_TS=$((LOAD_START_TS + WINDOW * 1000000000))

declare -A CLASS_NAMES
while IFS= read -r line; do
    cid=$(echo "$line" | awk '{print $2}')
    cname=$(echo "$line" | awk '{print $4}')
    CLASS_NAMES[$cid]="$cname"
done < <(grep '^Class ' "$PROFILE_BEFORE")

> "$FORCE_INIT_LIST"
while IFS= read -r line; do
    ts=$(echo "$line" | awk -F'|' '{print $1}' | tr -d ' ')
    classid=$(echo "$line" | awk -F'|' '{print $2}' | awk '{print $2}')
    if [ "$ts" -gt "$LOAD_START_TS" ] 2>/dev/null && [ "$ts" -le "$WINDOW_END_TS" ] 2>/dev/null; then
        cname="${CLASS_NAMES[$classid]:-}"
        if [[ -n "$cname" && "$cname" != *'$$Lambda$'* && "$cname" != *'/0x'* ]]; then
            echo "$cname" >> "$FORCE_INIT_LIST"
        fi
    fi
done < <(grep '| ClassInit ' "$PROFILE_BEFORE")

# Deduplicate
sort -u -o "$FORCE_INIT_LIST" "$FORCE_INIT_LIST"

echo "    Force-init list ($FORCE_INIT_LIST):"
while IFS= read -r cls; do
    echo "      $cls"
done < "$FORCE_INIT_LIST"
echo ""

# ── Step 5: Re-run with force init (ProfileLogIn + force flags) ───
echo ">>> Step 5: Re-running with ProfileForceClassInitialization..."
"$JAVA" \
    -XX:+UnlockExperimentalVMOptions \
    -XX:ProfileLogIn=demo_before \
    -XX:ProfileLogOut=demo_after \
    -XX:ProfileForceClassInitializationDelaySec="$FORCE_INIT_DELAY" \
    -XX:ProfileForceClassInitializationListPath="$FORCE_INIT_LIST" \
    -cp "$SCRIPT_DIR/src" \
    FintechApp "$LOAD_START" "$WINDOW"
echo ""

# ── Step 6: Verify fix ───────────────────────────────────────────
echo ">>> Step 6: Verifying fix..."
echo ""

VMSTART_AFTER=$(grep '| VmStart' "$PROFILE_AFTER" | head -1 | awk -F'|' '{print $1}' | tr -d ' ')
LOAD_START_TS_AFTER=$((VMSTART_AFTER + LOAD_START_NS))
WINDOW_END_TS_AFTER=$((LOAD_START_TS_AFTER + WINDOW * 1000000000))

declare -A CLASS_NAMES_AFTER
while IFS= read -r line; do
    cid=$(echo "$line" | awk '{print $2}')
    cname=$(echo "$line" | awk '{print $4}')
    CLASS_NAMES_AFTER[$cid]="$cname"
done < <(grep '^Class ' "$PROFILE_AFTER")

APP_CLASSES_REMAINING=0
while IFS= read -r line; do
    ts=$(echo "$line" | awk -F'|' '{print $1}' | tr -d ' ')
    classid=$(echo "$line" | awk -F'|' '{print $2}' | awk '{print $2}')
    if [ "$ts" -gt "$LOAD_START_TS_AFTER" ] 2>/dev/null && [ "$ts" -le "$WINDOW_END_TS_AFTER" ] 2>/dev/null; then
        cname="${CLASS_NAMES_AFTER[$classid]:-}"
        if [[ -n "$cname" && "$cname" != *'$$Lambda$'* && "$cname" != *'/0x'* ]]; then
            APP_CLASSES_REMAINING=$((APP_CLASSES_REMAINING + 1))
            echo "    STILL LATE: $cname (+$(( (ts - VMSTART_AFTER) / 1000000 ))ms)"
        fi
    fi
done < <(grep '| ClassInit ' "$PROFILE_AFTER")

echo ""
if [ "$APP_CLASSES_REMAINING" -eq 0 ]; then
    echo "RESULT: FIXED"
    echo "All application classes are now initialized before the ${LOAD_START}s load start."
    echo "Remaining post-load-start events (if any) are JVM-internal classes."
else
    echo "RESULT: $APP_CLASSES_REMAINING application class(es) still past load start."
    echo "Review the force-init list or increase ProfileForceClassInitializationDelaySec."
fi

Example 2: detect_post_deadline_classinit.sh


#!/bin/bash
#
# detect_post_deadline_classinit.sh
#
# Scans a ReadyNow ProfileLogOut dump file for ClassInit/ClassInitEnd events
# that occur AFTER load start.
#
# Any post-load-start ClassInit events indicate classes whose initialization
# is deferred beyond load start, blocking ReadyNow compilation replay.
#
# Usage:
#   ./detect_post_deadline_classinit.sh <profile_output_file> [load_start_seconds] [window_seconds]
#
#   profile_output_file  - Path to the ProfileLogDumpOutputToFile output
#   load_start_seconds   - Load-start boundary in seconds (default: 30)
#   window_seconds       - How long after load start to consider (default: 10).
#                          ClassInit events after load_start + window are ignored
#                          (e.g. shutdown-only classes).
#
# Exit codes:
#   0 - No post-load-start ClassInit events found (clean)
#   1 - Post-load-start ClassInit events detected (analysis needed)
#   2 - Usage error or file not found
#

set -euo pipefail

if [ $# -lt 1 ]; then
    echo "Usage: $0 <profile_output_file> [load_start_seconds] [window_seconds]"
    exit 2
fi

PROFILE="$1"
if [ ! -f "$PROFILE" ]; then
    echo "ERROR: File not found: $PROFILE"
    exit 2
fi

# --- Verify ProfileLogOut format version ---
# This script was written against ZingProfile version 64. If the profile
# format version has been bumped, the layout of Class/ClassInit/VmStart
# records may have changed and this script's parsing could be silently wrong.
EXPECTED_PROFILE_VERSION=64
PROFILE_VERSION=$(grep -m1 '^ZingProfile ' "$PROFILE" | awk '{print $2}')
if [ -z "$PROFILE_VERSION" ]; then
    echo "WARNING: No 'ZingProfile <version>' header found in $PROFILE."
    echo "         Cannot confirm profile format; results may be unreliable."
    echo ""
elif [ "$PROFILE_VERSION" != "$EXPECTED_PROFILE_VERSION" ]; then
    echo "=========================================="
    echo " WARNING: ProfileLogOut format version mismatch"
    echo "=========================================="
    echo " Expected: ZingProfile $EXPECTED_PROFILE_VERSION"
    echo " Found:    ZingProfile $PROFILE_VERSION"
    echo ""
    echo " MANUAL ACTION REQUIRED: verify that the profile record layout"
    echo " (VmStart / Class / ClassInit lines) has not changed in a way"
    echo " that would invalidate this script's parsing. If the format is"
    echo " still compatible, update EXPECTED_PROFILE_VERSION to $PROFILE_VERSION."
    echo "=========================================="
    echo ""
fi

# --- Extract VmStart timestamp (nanoseconds) ---
VMSTART=$(grep '| VmStart' "$PROFILE" | head -1 | awk -F'|' '{print $1}' | tr -d ' ')
if [ -z "$VMSTART" ]; then
    echo "ERROR: No VmStart event found in profile"
    exit 2
fi

# --- Determine load start ---
if [ $# -ge 2 ]; then
    LOAD_START_SEC="$2"
else
    LOAD_START_SEC=30
    echo "NOTE: No load start specified; using default ${LOAD_START_SEC}s"
fi

if [ $# -ge 3 ]; then
    WINDOW_SEC="$3"
else
    WINDOW_SEC=10
fi

LOAD_START_NS=$((LOAD_START_SEC * 1000000000))
LOAD_START_TS=$((VMSTART + LOAD_START_NS))
WINDOW_END_TS=$((LOAD_START_TS + WINDOW_SEC * 1000000000))

echo "=========================================="
echo " ReadyNow ClassInit Load-Start Check"
echo "=========================================="
echo "Profile:    $PROFILE"
echo "VmStart:    $VMSTART"
echo "Load start: +${LOAD_START_SEC}s (ts=$LOAD_START_TS)"
echo "Window:     +${WINDOW_SEC}s after load start (ts=$WINDOW_END_TS)"
echo ""

# --- Build class ID -> name map ---
declare -A CLASS_NAMES
while IFS= read -r line; do
    cid=$(echo "$line" | awk '{print $2}')
    cname=$(echo "$line" | awk '{print $4}')
    CLASS_NAMES[$cid]="$cname"
done < <(grep '^Class ' "$PROFILE")

# --- Scan ClassInit events for post-load-start occurrences ---
POST_DEADLINE_COUNT=0
POST_DEADLINE_CLASSES=()

while IFS= read -r line; do
    ts=$(echo "$line" | awk -F'|' '{print $1}' | tr -d ' ')
    classid=$(echo "$line" | awk -F'|' '{print $2}' | awk '{print $2}')

    if [ "$ts" -gt "$LOAD_START_TS" ] 2>/dev/null && [ "$ts" -le "$WINDOW_END_TS" ] 2>/dev/null; then
        cname="${CLASS_NAMES[$classid]:-unknown(id=$classid)}"
        delta_ns=$((ts - VMSTART))
        delta_ms=$((delta_ns / 1000000))
        POST_DEADLINE_CLASSES+=("$cname (+${delta_ms}ms)")
        POST_DEADLINE_COUNT=$((POST_DEADLINE_COUNT + 1))
    fi
done < <(grep '| ClassInit ' "$PROFILE")

# --- Report results ---
TOTAL_CLASSINIT=$(grep -c '| ClassInit ' "$PROFILE")

echo "Total ClassInit events:             $TOTAL_CLASSINIT"
echo "Post-load-start ClassInit events:   $POST_DEADLINE_COUNT"
echo ""

if [ "$POST_DEADLINE_COUNT" -eq 0 ]; then
    echo "RESULT: CLEAN"
    echo "No ClassInit events after the ${LOAD_START_SEC}s load start."
    echo "ReadyNow compilation replay is not blocked by late class initialization."
    exit 0
else
    echo "RESULT: ANALYSIS NEEDED"
    echo ""
    echo "The following $POST_DEADLINE_COUNT classes were initialized AFTER the"
    echo "${LOAD_START_SEC}s load start. Any ReadyNow compilation that depends on these"
    echo "classes (via load/link/hierarchy closures) cannot be replayed until"
    echo "these classes are initialized, degrading warmup performance."
    echo ""
    echo "Post-load-start classes:"
    for entry in "${POST_DEADLINE_CLASSES[@]}"; do
        echo "  - $entry"
    done
    exit 1
fi

Example 3: FintechApp.java


import java.util.Random;

/**
 * Mock fintech app demonstrating eager vs lazy class initialization.
 *
 * Uses arrays and primitives instead of Collections/ConcurrentHashMap
 * to minimize JDK classes loaded at startup.
 *
 * Eager classes (MarketDataFeed, OrderRouter) initialize at startup.
 * Lazy classes (AuditLogger, EndOfDaySettlement) initialize after load start,
 * producing post-load-start ClassInit events in the ReadyNow profile.
 *
 */
public class FintechApp {

    static final Random random = new Random(42);

    static class MarketDataFeed {
        static final String[] symbols = {"AAPL", "GOOGL", "MSFT"};
        static final double[] prices = {187.50, 141.80, 378.25};
        static double getPrice(String symbol) {
            for (int i = 0; i < symbols.length; i++) {
                if (symbols[i].equals(symbol)) return prices[i];
            }
            return 0.0;
        }
        static void tick() {
            for (int i = 0; i < prices.length; i++) {
                prices[i] *= 1 + (random.nextDouble() - 0.5) * 0.001;
            }
        }
    }

    static class OrderRouter {
        static final String[] venues = {"NYSE", "NASDAQ", "BATS"};
        static String route(String symbol, double qty, double price) {
            String venue = venues[random.nextInt(venues.length)];
            return "ORDER " + symbol + " " + (int) qty + "@" + price + " -> " + venue;
        }
    }

    static class RiskEngine {
        static final double MAX_POSITION = 1_000_000.0;
        static final double[] positionLimits = new double[MarketDataFeed.symbols.length];
        static {
            for (int i = 0; i < positionLimits.length; i++) {
                positionLimits[i] = MAX_POSITION * (1.0 + random.nextDouble() * 0.5);
            }
        }
        static boolean riskEnabled() {
            return MAX_POSITION > 0;
        }
        static boolean checkLimit(String symbol, double qty, double price) {
            double notional = qty * price;
            for (int i = 0; i < MarketDataFeed.symbols.length; i++) {
                if (MarketDataFeed.symbols[i].equals(symbol)) {
                    return notional <= positionLimits[i];
                }
            }
            return false;
        }
    }

    static class AuditLogger {
        static int tradeCount;
        static int cancelCount;
        static final boolean riskEnabled;
        static {
            riskEnabled = RiskEngine.riskEnabled();
        }
        static void logTrade(String detail) {
            tradeCount++;
        }
    }

    static class EndOfDaySettlement {
        static final double[] settledPrices = new double[MarketDataFeed.symbols.length];
        static void settle(double[] prices) {
            System.arraycopy(prices, 0, settledPrices, 0, prices.length);
        }
    }

    public static void main(String[] args) throws Exception {
        int loadStartSeconds = 5;
        int runAfterSeconds = 10;
        if (args.length > 0) loadStartSeconds = Integer.parseInt(args[0]);
        if (args.length > 1) runAfterSeconds = Integer.parseInt(args[1]);

        System.out.println("=== FintechApp starting ===");
        System.out.println("Load start: " + loadStartSeconds + "s, run after: " + runAfterSeconds + "s");
        System.out.println();

        System.out.println("--- Startup initialization (before load start) ---");
        MarketDataFeed.tick();
        OrderRouter.route("AAPL", 100, MarketDataFeed.getPrice("AAPL"));

        System.out.println();

        System.out.println("--- Sleeping " + loadStartSeconds + "s until load start ---");
        Thread.sleep(loadStartSeconds * 1000L);
        System.out.println();

        System.out.println("--- Post-load-start lazy initialization ---");
        AuditLogger.logTrade("AAPL [email protected]");
        boolean allowed = RiskEngine.checkLimit("AAPL", 100, MarketDataFeed.getPrice("AAPL"));
        System.out.println("  >> Risk check for AAPL: " + (allowed ? "PASSED" : "BLOCKED"));
        EndOfDaySettlement.settle(MarketDataFeed.prices);

        System.out.println("--- Running " + runAfterSeconds + "s after load start ---");
        Thread.sleep(runAfterSeconds * 1000L);

        System.out.println();
        System.out.println("=== FintechApp complete ===");
    }
}
